CAPACITY:
Model EIA: Up to 1 1/2 gph Model EIIA: Up to 3 gph
WATER: Up to 80 psi without regulation. 1/4″ copper tube 1/8 npt.
DRAIN: Not necessary, but supplied.
MOTOR: 115/60/1, 1/4 hp, 3.0 amps, 3400 rpm, TENV, 220/50/1, 1/4 hp, 1.3 amps, 2800 rpm
WEIGHT: 30 lbs. Net, 35 lbs. Crated
DIMENSIONS: Crated: 18″ x 18″ x 15″
CAPACITY: Type H: Up to 8 gph or 67 lb/hr
WATER: No regulation necessary if between 10-35psi. 5/8″ FPT
DRAIN: 1 1/4″ drain, or recycling.
MOTOR: Type H: 115/60/1, 1/4 hp, 3.2 amps, 3450/2850 rpm,
TENV 230/50/1, 3.7-1.85 amps (same as above)
WEIGHT: Net: 57 lbs net, Crated: 85 lbs
DIMENSIONS: Crated: 31″ x 25″ x 22″
CAPACITY: Type L: Up to 12 gph or 100 lb/hr
WATER: No regulation necessary if between 10-35psi. 5/8″ FPT
DRAIN: 1 1/4″ drain, or recycling.
MOTOR: Type L: 230/60/3, 3/4 hp, 2.4 amps, 3450/2850 rpm,
TENV 460/50/60, 2.4 amps (same as above)
WEIGHT: Net: 75 lbs net, Crated: 96 lbs
DIMENSIONS: Crated: 31″ x 25″ x 22″
CAPACITY: Up to 1.75 gal/hr atomizer;
available in 6, 9, 12, and 15 lb/hr capacities.
WATER: Regulation for air and water.
DRAIN: Not required.
MOTOR: Not required.
WEIGHT: 1 lb. 8 oz.
